SuperNatural Power, Ride, and Range

The Specialized Science Club Introduces the Levo 4, an electric mountain bike so advanced it transforms you into a cycling cyborg. Together you're SuperNatural, fortified with super power, traction, control, and range to conquer any off-road terrain. Levo 4, Where Super Meets Natural.

E-Bike System

• UI/Remote: All New MasterMind T3 Display System, 2.2" high-resolution color screen, fully customizable with the Specialized app

• Motor: Specialized 3.1 Motor, 105Nm torque, 810W power

• Charger: Specialized 4-amp charger

• Battery: 840Wh battery

Frameset

• Frame: All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm

• Seat Binder: Alloy, 38.6mm

Suspension

• Fork: FOX 38 Performance Elite series, 29", GRIP X2 damper, 15x110mm axle, 44mm offset, 160mm of travel

• Rear Shock: FOX FLOAT X Performance Elite with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment

Brakes

• Front Brake: SRAM Maven Silver, 4-piston caliper, hydraulic disc, 220mm Rotor

• Rear Brake: SRAM Maven Silver, 4-piston caliper, hydraulic disc, 200mm rotor

Drivetrain

• Crankset: SRAM GX Eagle Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm

• Chainrings: SRAM 34t T-Type chainring, 104 BCD, steel

• Shift Levers: SRAM AXS POD Controller

• Rear Derailleur: SRAM GX Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery)

• Cassette: SRAM GX Eagle Transmission Cassette, 12-speed, 10-52t

• Chain: SRAM GX Eagle Transmission Flattop Chain

Wheels & Tires

• Front Wheel: Roval Traverse Alloy 29", DT Swiss 370, 15x110mm, 28h

• Rear Wheel: Roval Traverse Alloy 27.5", DT Swiss 370 XD freehub body, 12x148mm, 32h

• Front Tire: Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"

• Rear Tire: Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"

• Inner Tubes: Standard, Presta valve

Cockpit

• Handlebars: Alloy handlebars, 35mm diameter, 8-degree backsweep, 6-degree upsweep (S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise)

• Stem: Alloy Trail Stem, 35mm bar bore

• Grips: Deity Lockjaw grips

• Saddle: Bridge Comp, Hollow Cr-mo rails

• SeatPost: PNW Loam post w/travel adjust (S2: 125mm, S3: 170mm, S4/S5/S6: 200mm)

Accessories & Details

• Accessories (SWAT): SWAT internal downtube storage

• Product ID: 218704

• Compliance Certification: As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS.

Weight

• Weight: 24.41 kg (53 lb, 13.0 oz)

• Weight Size: S4

SIZING

This is our simplified version of Specialized's size chart. We believe their official chart has a bit too much overlap, which can easily get confusing! For the absolute best fit, contact us or visit the store to test them out!
