E-MTB Specifications Overview

Electric Drive System & Power

• Motor: Bosch Performance Line CX

  • Torque: 85 NM (Upgradeable to 100 NM via Flow App, available in summer)

• Battery: Bosch PowerTube Li-Ion (600 Wh)

• Display & Control: Bosch Mini Remote + System Controller

Frame and Suspension (Gravity Focus)

• Frame: Aluminium construction (Full Suspension)

• Fork: FOX 38 Factory, GRIP X2 damper

  • Travel: 170 mm

• Shock: FOX DHX Performance (Coil Shock)

  • Travel: 165 mm

  • Coil Rates: Size-specific (350/400/500/600 lbs for S/M/L/XL)

Drivetrain

• Shifting System: SRAM Eagle 90 Transmission (T-Type)

• Rear Derailleur: SRAM Eagle 90 Transmission, 12-speed

• Cassette: SRAM GX Transmission, 10-52T

• Chain: SRAM GX Eagle Transmission

• Crankset: Samox, 165 mm

• Chainring: SRAM Eagle Transmission, 36 T

Brakes, Wheels, and Tires

• Brakes (Front/Rear): TRP EVO Pro, 4-piston hydraulic disc brakes

• Disc Brake Rotors (F/R): TRP RS01E, 220 mm diameter on both front and rear

• Wheelset: DT Swiss HF 1900, alloy

  • Configuration: Mullet setup (Front: 29" | Rear: 27.5")

• Tires (F/R): Schwalbe Magic Marry, Super DH casing, ADDIX Ultra Soft compound

  • Size: 29 x 2.4" (Front) | 27.5 x 2.4" (Rear)

Cockpit and Finishing Components

• Handlebar: OneUp Riser, 800 mm width, 35 mm rise

• Stem: FOCUS C.I.S. 2.0, 40 mm (Cockpit Integration Solution)

• Grips: ODI Elite Pro

• Saddle: fi'zi:k Ridon X5

• Seatpost: OneUp V3 Dropper Post

  • Travel: Generous, size-specific travel (150 - 210 mm)

• Headset: ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated angle headset

Weight and Capacity

• Weight: 26 kg (with 600 Wh battery)

• Permissible System Weight: 150 kg (rider + bike + gear)
