Pedal have also fitted the Pedal Derby Electric Folding Bike with a full-sized 250W hub motor in the rear wheel (to ensure great traction and improved safety compared to a front-wheel-motor equipped bike), plus a reliable 7-Speed Shimano Tourney derailleur. The motor is powered by a 374Wh lithium-ion battery which is also removable for easy charging away from the bike, or to make the bike lighter to carry. The battery is positioned conveniently behind the seat post, leaving ample room for a light load such as some pannier bags or a basket on the rear rack, making this little powerhouse the ideal commuter!
| FRAME MATERIAL | ALLOY |
| FRAME DESCRIPTION | FOLDING STEP THROUGH ALLOY 6061 POD BATTERY |
| FRAME STYLE | FOLDING |
| FORK MATERIAL | STEEL |
| FORK BRAND | PEDAL |
| FORK DESCRIPTION | RIGID STEEL |
| FRONT TRAVEL | |
| DERAILLEUR FRONT | 1X |
| DERAILLEUR REAR | SHIMANO TOURNEY 7 SPEED |
| GROUPSET | SHIMANO MIXED |
| SHIFTERS | LTWOO TRIGGER 7 SPEED |
| BRAKES | TEKTRO HD-M275 |
| BRAKE TYPE | HYDRAULIC DISC BRAKE |
| ROTOR FRONT | 160MM 6 BOLT |
| ROTOR REAR | 160MM 6 BOLT |
| CRANKSET AND FRONT CHAINRINGS | 52T - ED STEEL W/DOUBLE CHAINRING, 170MM ALLOY ARM |
| BOTTOM BRACKET | SEALED BSA CARTRIDGE 119MM |
| CHAIN | KMC Z7 116L |
| PEDALS | FOLDING PLASTIC 9/16" |
| REAR GEARS | 7 SPEED |
| CASSETTE DESCRIPTION | SHIMANO TZ500 14-28T |
| HANDLEBAR | DNF-A806 ALLOY 600MM 30MM RISE 6 DEG SWEEP |
| HANDLEBAR STEM | FH05W TELESCOPIC & FOLDING 160-240MM ALLOY |
| HEADSET | INTEGRATED 44MM |
| GRIPS / BAR TAPE | XL G78 125MM ERGO RUBBER |
| SEAT POST | 350MM 30.9MM ALLOY SINGLE BOLT |
| SADDLE | QF3103 ERGO SADDLE |
| FRONT AND REAR HUBS | F: ALLOY LBB W/NUTTED 6 BOLT / R: ELECTRIC GEARED HUB MOTOR NUTTED |
| FRONT AND REAR RIMS | ALLOY DOUBLE WALL 20" 36H 13G |
| FRONT AND REAR TYRES | KENDA K1040 20X2.3 CITY TYRE |
| WHEEL SIZE | 20" |
| FRONT AND REAR LIGHTS | |
| FENDER | 65MM PVC BLACK GLOSS |
| ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER) | KICKSTAND + 42V 2A CHARGER (3 PIN FOR 36V BATTERY) |
| DRIVE UNIT LOCATION | REAR WHEEL |
| DRIVE UNIT DESCRIPTION | REAR PLANETARY DRIVE |
| MOTOR POWER (WATTS) | 250 |
| MOTOR TORQUE (NM) | 30 |
| BATTERY DESCRIPTION | REMOVABLE POD BATTERY 36V |
| BATTERY SIZE (WATT-HOURS) | 374 |
| CHARGE TIME (HOURS) | 5 |
| DISPLAY | KD-58C |
| ASSIST MODES | 5 MODES |
| RANGE (KMS) | 50 |
| IP RATING | IP54 |
| WEIGHT LIMIT | 100KG |
